Cast Aluminum Welded TerminalCatalog ID: 01B3D2F
Cast Aluminum Weldment Terminal is one kind of Utility connectors used on overhead line construction.
Aluminum with lower density than other metals.
It forms a protective layer of oxide to protect the terminal when it exposes to the air.
2 Bolt Holes and 2 Pad Holes
Used with AAC and ACSR conductors
Contact Us
Categories: Conductor Hardware, Lug & Terminal, Power Line Hardware
Product Details | Resources and Downloads
Product Details | Resources and Downloads
Product Details
General
MaterialAluminumNumber of Bolt Holes2Number of Pad Holes2TypeTerminal, Aluminum Weldment
Dimensions
Angle – Pad180 °Weight0.686 lb (0.31 kg)Width – Pad2 in (50.8 mm)
Conductor Related
Conductor CompatibilityACSR-Teal-605-30/19;ACSR-Grosbeak-636-26/7;ACSR-Egret-636-30/19;ACSR-Flamingo-666.6-24/7;ACSR-Gannet-666.6-26/7;AAC-Cattail-750-61;AAC-Arbutus-795-37;AAC-Lilac-795-61Conductor Diameter – Maximum1.028 in (26.11 mm)Conductor Diameter – Minimum0.99 in (25.15 mm)Conductor Diameter Range0.99 – 1.028Conductor TypeAAC
ACSR
